EP-M150 Metal 3D Printer
EP-M150 Metal 3D Printer
The EP-M150 uses a fiber laser to directly melt elemental or alloy metal powders to form complex structures and parts. The EP-M150 has a variety of small metal applications in fields such as, material development, medical implants, dental, and jewelry.
Features
High Precision Printing Quality & High Efficiency
∙ Small laser facula and thin layer thickness guarantee more precise printing quality.
∙ Intelligent powder coating method and faster scanning speed.
∙ Unique scanning path and oxygen control assure high-quality printing.
Low-cost operation
· 500 crowns printed using only 1KG of powder
· Improved powder feeding and sieving system enables high material utilization
· Gas consumption≤<0.2L/min(0.3±0.1MPa) (Printing period)
· Optimized chamber structure and excellent sealing properties minimize gas consumption
Easy Maintenance
· Intuitive user interface
· Optimized structure design for easier maintenance
High Safety
· Integrates more than 10 security technologies
· Working environment and real-time gas monitoring
Specification
Build Volume: Φ150mmx120mm
Laser: Fiber laser,200W/500W(optional)
Optical System Configuration: Single laser system / dual-laser system (optional)
Spot Size: 40~60μm
Max Scan Speed: 8m/s
Layer Thickness: 20-100μm
Max Build Speed: 12cm³/h (single laser system) 18cm³/h (dual laser system)
Material:Titanium Alloy, Aluminium Alloy, Nickel Alloy, Maraging Steel, Stainless Steel, Cobalt Chrome, Copper Alloy, etc.
Power: 220V,12A,50~60Hz, 3.5kW
Gas Supply: Ar/N₂
Oxygen Content of Chamber: ≤100ppm
Dimensions (W*D*H): 1750*799*1828mm³
Machine Weight: Around 900kg
Control Software: Eplus3d Print Software
Input Data Format: STL or other convertible file
